My static website on AWS S3 and CloudFront

How I created a static website on AWS S3 and CloudFront with nice redirects and security headers.

Requirements

• HTTPS
  • Redirect from http to https
  • Support https on all websites
• Use www URLs
  • Redirect from jarett-lee.com to www.jarett-lee.com
• /path/ is the canonical URL
  • Redirect from /path to /path/
  • Redirect from /path/index.html to /path/
  • Serve files like normal, such as /style.css
• Redirect common misspellings
  • Redirect from jarrett-lee.com to www.jarett-lee.com
  • Redirect from jarettlee.com to www.jarett-lee.com

Why are these my requirements?

Important requirements

• HTTPS - https is standard and secure
• Redirect common misspellings - I’ve seen jarett misspelled as jarrett too many times
• Canonical URL - I don’t want to include a rel=“canonical” link in every file, so I need redirects to signal which URL is the canonical URL

Preferences

• Use www URLs - I like how www.jarett-lee.com looks and www is slightly more flexible
• /path/ is the canonical URL - I like how /path/ looks better than /path/index.html and /path

Primary resources

These resources fulfill all my requirements except the additional common misspelling domains.

1. Domain - Route 53 > Domains > Registered domains
   • $13.00 a year per .com domain
   • > Register Domain
   • Domain name: jarett-lee.com
2. Hosted zone - Route 53 > Hosted zones
   • $0.50 a month per hosted zone
   • > Create hosted zone
   • The NS record and SOA record should be created automatically
3. SSL/TLS certificate - AWS Certificate Manager > Certificates
   • > Request
   • Fully qualified domain name:
     • jarett-lee.com
     • *.jarett-lee.com
4. SSL/TLS CNAME record - AWS Certificate Manager > Certificates > [certificate id for jarett-lee.com]
   • > Create records in Route 53
5. Bucket - Amazon S3 > Buckets
   • This is where your website will live
   • The folder structure in the bucket should have a /index.html file for the home page and /path/index.html
   • > Create bucket
   • Bucket name: personal-website
6. Response headers policy - CloudFront > Policies > Response headers
   • This policy is probably more strict than necessary, but it’s perfect for my static website
   • > Create response headers policy
   • Response headers policy name: StaticWebsiteHeadersPolicy
   • Strict-Transport-Security: enable
     • max-age seconds: 63072000
     • preload: check
     • includeSubDomains: check
   • X-Content-Type-Options: enable
   • X-Frame-Options: enable
     • Origin: DENY
   • X-XSS-Protection: enable
     • X-XSS-Protection: Enabled
     • block: check
   • Referrer-Policy: enable
     • Referrer-Policy: strict-origin-when-cross-origin
   • Content-Security-Policy: enable
     • Content-Security-Policy: default-src ‘none’; img-src ‘self’; script-src ‘self’ ‘unsafe-eval’; style-src ‘self’; object-src ‘none’
7. CloudFront function - CloudFront > Functions
   • > Create function
   • CloudFront function name: RedirectFunction
   • See code below
8. CloudFront distribution - CloudFront > Distributions
   • The resources don’t have to be created in this order, but going in this order means you don’t have to jump between create pages and refresh resource lists
   • I use the cheapest edge locations because my website doesn’t get much traffic
   • > Create distribution
   • Origin domain: personal-website
   • Orign access: Origin access control settings (recommended)
   • Viewer protocol policy: Redirect HTTP to HTTPS
   • Response headers policy: StaticWebsiteHeadersPolicy
   • Viewer request:
     • Function type: CloudFront Functions
     • Function ARN / Name: RedirectFunction
   • Price class: Use only North America and Europe
   • Alternate domain name (CNAME):
     • jarett-lee.com
     • www.jarett-lee.com
   • Custom SSL certificate: jarett-lee.com ([certificate id])
   • Supported HTTP versions:
     • HTTPS/2: check
     • HTTPS/3: check
9. Bucket policy
   • CloudFront > Distributions > [CloudFront distribution for jarett-lee.com] > Origins > Edit
     • > Copy policy
     • > Go to S3 bucket permissions
   • Amazon S3 > Buckets > personal-website > Permissions > Bucket policy
     • > Edit
10. Bare A record - Route 53 > Hosted zones > jarett-lee.com
    • > Create record
    • Record type: A
    • Alias: enable
    • Route traffic to: Alias to CloudFront distribution
    • Choose distribution: jarett-lee.com ([CloudFront domain name])
11. www CNAME record - Route 53 > Hosted zones > jarett-lee.com
    • Copy the domain name from the previous record, but remove the extra period at the end of the domain name
    • > Create record
    • Record name:
      • subdomain: www
    • Record type: CNAME
    • Value: [CloudFront domain name]

CloudFront function name: RedirectFunction

function handler(event) {
    var request = event.request
    var headers = request.headers
    var host = request.headers.host && request.headers.host.value
    var uri = request.uri

    var redirect = false

    var errorResponse = {
        statusCode: 500,
        statusDescription: 'Internal Server Error',
    }

    var targetHost = 'www.jarett-lee.com'
    if (!host) {
        return errorResponse
    } else if (host !== targetHost) {
        redirect = true
    }

    var newUri = uri
    var prefixPath = uri.match('(.*/)index.html')
    if (uri.length === 0 || uri === '/') {
        request.uri = '/index.html'
    } else if (uri.length === 1) {
        return errorResponse
    } else if (uri.match('.*/$')) {
        request.uri += 'index.html'
    } else if (prefixPath) {
        newUri = prefixPath[1]
        redirect = true
    } else if (request.uri.match('/[^/.]+$')) {
        newUri = request.uri + '/'
        redirect = true
    }

    if (redirect) {
        var newUrl = `https://${targetHost}${newUri}`
        var response = {
            statusCode: 301,
            statusDescription: 'Found',
            headers: {
                "location": { "value": newUrl },
            },
        }

        return response
    }

    return request
}

Redirect resources

These resources my common misspelling domain requirements.

1. Repeat steps 1-4 with the new domain
   • Domain - Route 53 > Domains > Registered domains > Register Domain
   • Hosted zone - Route 53 > Hosted zones > Create hosted zone
   • SSL/TLS certificate - AWS Certificate Manager > Certificates > Request
   • SSL/TLS CNAME records - AWS Certificate Manager > Certificates > [certificate id] > Create records in Route 53
2. Skip to step 8 and create a CloudFront distribution
   • The other resources have already been created
   • CloudFront distribution - CloudFront > Distributions > Create distribution
3. Skip step 9, updating the bucket policy
   • The redirect distribution should never make a request to the bucket due to the redirect function, so the origin doesn’t matter
4. Repeat steps 10 and 11 with the new domain
   • Bare A record - Route 53 > Hosted zones > [domain] > Create record
   • www CNAME record - Route 53 > Hosted zones > [domain] > Create record

Design decisions

What I used to do in the past

I used to use a Lambda@Edge origin request function to handle redirects and another Lambda@Edge origin response function to add response headers because CloudFront functions and response headers policies didn’t exist in 2012 and I didn’t want to run a Lambda@Edge function on every request.

Now, the AWS documentation recommends using CloudFront functions for redirects and response headers.

301 vs 302 redirects

I use a 301 permanent redirect instead of a 302 temporary redirect because I don’t plan to change my redirecting scheme.

Additional things I did

Turn on standard logging

1. Bucket - Amazon S3 > Buckets
   • > Create bucket
   • Bucket name: personal-website-logs
2. CloudFront Distribution - CloudFront > Distributions > [distribution id] > General > Settings
   • > Edit
   • Standard logging: On
   • S3 bucket: personal-website-logs
   • > Enable ACLs

Use a different response headers policy for certain paths

The majority of my website is pure html, so I have a very strict response headers policy, but I wanted to host some coding projects on my website as well, so I wanted a different response headers policy for the /random/* path.

1. Response headers policy - CloudFront > Policies > Response headers
   • > Create response headers policy
2. CloudFront Distribution - CloudFront > Distributions > [distribution id] > Behaviors
   • Copy the settings from the existing distribution except for the settings listed here
   • > Create behavior
   • Path pattern: /random/*
   • Response headers policy: [response headers policy]

Things I didn’t want, but I could’ve done

• Redirect from /path/file.html to /path/file/
  • If you want this, edit the RedirectFunction

Things I wanted, but I couldn’t figure out

I wanted

• To block direct access to the CloudFront domain name
• Less steps to create a redirect; creating a CloudFront distribution feels like overkill
